Pallet Hook

Pallet Hook is a versatile unit that features adjustable body height and tin width positioning, making this unit ideal for use in the transport and construction industries.

Pallet Hook PHA

The PHA 2000 automatic pallet hook is self-leveling, using an internal spring mechanism, ensuring the lifting eye is in the correct position, to keep the fork tines horizontal

- The Pallet Hook PHA auto-adjusts for differing centers of gravity

- Used by crane and other lifting equipment

- Enclosed big spring mechanism can automatically maintain the forks with horizontal balance in use, to protect moving loads

- Adjustment tine width

- Surface treatment: painted or galvanized finish



Pallet Hook PHD

The PHD 2200 pallet hook is a versatile unit that features adjustable body height and tin width positioning, making this unit ideal for use in the transport and construction industries.

- Used by crane and other lifting equipment

- Both body height and space between forks are adjustable

- Adjusting lifting ring to maintain overall balance

- Two options available, with different loading capacities.

- Surface treatment: painted or galvanized finish


TypeSWL
Load CentreOverall Width
Overall Depth
Overall Height
Unit Weight

(kg)(mm)(mm)(mm)(mm)(kg)
PHA20002000600101012001840196
PHD22002200600101012001315-1915215
CHM2002000600101012001580225
