One of the most essential products in many sectors, designed with high-quality materials so that it can serve you many years and available with different make couplings.
The bucket is designed for optimal loading and emptying angle. Made of high quality steel for best durability.
Features:
- Reinforced steel blade increases the wear resistance
- High quality of the welding process increases the durability
- Different capacities
- Different brand connections
| Model | Width | Mounting Class | Capacity | Volume Capacity | Weight |
| (mm) | (kg) | (m³) | (Kg) | ||
| CD10E-C001-1400 | 1400 | ISO 3 | 1000 | 0.5 | 175 |
| CD26E-C002-1800 | 1800 | ISO 3 | 2600 | 1.3 | 418.8 |
| CD16G-5882-2030 | 2030 | SMS | 1600 | 0.8 | 198.9 |
| CD19.5G-5887-2730 | 2730 | Euro | 1950 | 0.98 | 251.3 |
| CD14.5G-5894-1830 | 1830 | Volvo L30 | 1450 | 0.72 | 184.8 |
| CD14.5G-WGG-1830 | 1830 | Without coupling | 1450 | 0.72 | 178.5 |
| CD12.5H-5882-1730 | 1730 | SMS | 1250 | 0.63 | 172.5 |
| CD11H-WGG-1530 | 1530 | Without coupling | 1100 | 0.56 | 158.37 |
| CD46J-5892-2300 | 2300 | Big BM | 4600 | 2.3 | 709.63 |
| CD35.5K-5882-2630 | 2630 | SMS | 3550 | 1.77 | 363.7 |
| CD33K-MT750-2430 | 2430 | MTFaste | 3300 | 1.65 | 370.14 |
| CD15L-589v/10°-2700 | 2700 | Volvo L30/10° | 1500 | 0.76 | 429 |
| CD06M-WGG-1400 | 1400 | Without coupling | 600 | 0.3 | 163.5 |
| CD06M-5882-1400 | 1400 | SMS | 600 | 0.3 | 185 |
| CD05M-AC10-1200 | 1200 | Avant 300/700 | 500 | 0.25 | 149 |
| CD18N-5887-2400 | 2400 | Euro | 1800 | 0.9 | 267 |
| CD40P-5882-2270 | 2270 | SMS | 4000 | 2 | 604 |
| CD11Q-AC10-1400 | 1400 | Avant 300/700 | 1100 | 0.53 | 122 |
| CD12.5Q-AC10-1600 | 1600 | Avant 300/700 | 1250 | 0.61 | 132 |
| CD17R-WGG-2000 | 2000 | Without coupling | 1700 | 0.85 | 272 |
| CD20S-5882-2200 | 2200 | SMS | 2000 | 1 | 279 |
| CD15S-WGG-1800 | 1800 | Without coupling | 1500 | 0.75 | 227 |
| CD03.5T-AC1-1100 | 1100 | Avant 300/700 | 350 | 0.17 | 123 |
| CD18U-WGG-2500 | 2500 | Without coupling | 1800 | 0.9 | 404 |
| CD15.5U-L30-2200 | 2200 | L30 | 1550 | 0.78 | 319 |
| CD15.5U-5887-2200 | 2200 | Euro | 1550 | 0.78 | 386 |
| CD14U-5882-2000 | 2000 | SMS | 1400 | 0.7 | 366 |
| CD24U-5892-2500 | 2500 | Big BM | 2400 | 1.21 | 712 |
| CD29W-WGG-2500 | 2500 | Without coupling | 2900 | 1.45 | 409 |
| CD26W-5887-2140 | 2140 | Euro | 2600 | 1.3 | 381 |
| CD26W-5892-2200 | 2200 | Big BM | 2600 | 1.3 | 418 |
| CD24W-LBZM420-2000 | 2000 | LBZM420 | 2400 | 1.2 | 386.5 |
| CD22W-L30-1800 | 1800 | L30 | 2200 | 1.1 | 368.5 |
| CD24W-5887-2000 | 2000 | Euro | 2400 | 1.2 | 366 |
| CD22W-5882-1800 | 1800 | SMS | 2200 | 1.1 | 348 |
Note
* Further technical details are available upon request
